CCTV Fixed Tubular Flange Mounted Columns
CCTV Fixed Tubular Flange Mounted Columns
This solution offers a cost-effective way to achieve the desired camera height, with off-the-shelf options available up to 8 metres. It boasts excellent stability, minimizing camera movement, making it ideal for use in public access areas. The column is designed with aesthetics in mind, making it a desirable choice when appearance is important. It features a flange-mounted type FM root, with pocket-type roots available for locations with restricted foundation space. The cable management is fully concealed, ensuring a clean and organized installation. Additionally, the structure has a hot-dipped galvanised finish, providing maximum weather protection and low maintenance requirements. Custom and bespoke versions can be tailored to meet specific customer needs, and clamp-on camera brackets are also available for added versatility.
**LEAD TIME IS 1 TO 2 WEEKS TO MOST UK POSTCODES. COLLECTION MAY BE POSSIBLE, CONTACT US TO FIND OUT MORE INFORMATION**
We can also offer other column types such as hinged, cabinet based columns and many more. Contact us for more information. Other heights are also available but not kept in stock. Lead time for these requests is around 3 to 5 weeks.
Key Features & Benefits:
✅ Robust, Future-Proof Build
Hot-dipped galvanized to BS EN ISO 1461:2009 standards, this column resists corrosion, rust, and UV degradation, even in coastal or high-humidity settings.
✅ Seamless Customisation
Customise the column to your project’s needs:
• Finishes: Standard Hot Dipped Galvanized. Any RAL colour (upon request).
✅ Manufactured to multiple standards
• Structural Steelwork: BS EN 10210-1:1994, BS EN 10210-2:1997
• General Steelwork: BS1449:1991, BS1387:1985, BS EN 10025:1993
• Welding Procedures: Comply with BS EN 1011-2:2001
• Fasteners: Grade 8.8 BS3692:2001, BS4190:2001, DIN93 I, DIN934
• Design Wind Loading: In accordance with CP3 chapter V Pt 2 & BS 6399 Pt 2:1997
Technical Specifications:
• Standard pan and tilt fixing of 101.6 PCD.
• Inspection / jointing aperture with backboards as standard feature.
• Equipment loading of up to 25kg.
• Buried root or flange mounted versions available.
• Standard heights available from 4 to 10 metres.
• Compatible with adaptors, accessories and anticlimbs.
Customisation Options Available!
Need a specific RAL colour? Contact our Sales Team at 01536 264064 or enquiries@wydels.co.uk to discuss bespoke solutions.
