50W to 200W Exterior CORE LED Floodlight Driverless IP65

50W to 200W CORE LED Floodlight – Wattage & Colour Selectable with 7 Year Warranty

The CORE LED Floodlight is a versatile, high-efficiency exterior floodlight designed for commercial, industrial, amenity and general area lighting applications.

Available across three wattage-selectable body sizes covering outputs from 50W to 200W, the CORE range allows the installed power to be adjusted to suit the requirements of the project. Each fitting is also colour-temperature selectable between 3000K, 4000K and 5000K, providing additional flexibility from a single luminaire.

With an efficacy of up to approximately 157 lumens per watt at 4000K, a wide 110° symmetrical beam and durable die-cast aluminium construction, the CORE is well suited to car parks, commercial yards, building perimeters, schools, horse arenas, general sports areas and exterior security lighting.

The range is supplied with a 7-year warranty.

Key Features

• Three wattage-selectable body sizes covering 50W to 200W
• 50/80/100W selectable model
• 100/120/150W selectable model
• 100/150/200W selectable model
• 3000K, 4000K and 5000K colour-temperature selectable
• Up to approximately 157lm/W at 4000K
• 110° symmetrical beam distribution
• Driverless LED floodlight design
• Die-cast aluminium housing with toughened glass
• IP65 rated for exterior use
• Instant-on operation
• Operating temperature from -40°C to +45°C
• Suitable for column-mounted or building-mounted installations
• 7-year warranty
• Free professional lighting-design support available from Wydels

Wattage-Selectable Models

The CORE range is available in three physical body sizes, each providing a choice of three power settings.

50W / 80W / 100W CORE

The smallest CORE model can be set to 50W, 80W or 100W and is suited to smaller commercial areas, building-mounted lighting, entrances, pathways, smaller yards and lower mounting heights.

At 4000K, the published outputs are approximately:

• 50W – 8,194 lumens
• 80W – 13,110 lumens
• 100W – 16,387 lumens

100W / 120W / 150W CORE

The mid-size CORE model provides selectable outputs of 100W, 120W or 150W and is suitable for larger car parks, commercial yards, industrial sites and general area lighting.

At 4000K, the published outputs are approximately:

• 100W – 17,043 lumens
• 120W – 20,452 lumens
• 150W – 25,565 lumens

100W / 150W / 200W CORE

The largest CORE model can be set to 100W, 150W or 200W and provides the highest output within the range for larger exterior areas and higher mounting positions.

At 4000K, the published outputs are approximately:

• 100W – 16,030 lumens
• 150W – 24,045 lumens
• 200W – 32,060 lumens

This selectable approach also makes it easier to use different output levels across a single project while retaining the same luminaire family and appearance.

Colour Temperature Options

Each CORE LED Floodlight is selectable between three colour temperatures.

3000K Warm White

3000K provides a warmer appearance and may be preferred for residential surroundings, amenity areas and projects where a softer night-time environment is required.

4000K Cool White

4000K provides a balanced neutral-to-cool white appearance and is generally our preferred option for commercial car parks, yards, schools and general exterior lighting.

5000K Daylight White

5000K provides a cooler, crisper appearance and may be used where high visual definition is preferred.

110° Symmetrical Beam

The CORE uses a wide 110° symmetrical light distribution.

This provides broad general-area coverage and makes the fitting particularly suitable where floodlights are mounted around or within the area being illuminated.

For projects requiring greater forward projection or tighter optical control, an asymmetric or specialist floodlight may provide a more suitable solution. Our free lighting-design service can help determine the most appropriate fitting and optic for the site.

Typical Applications

The CORE LED Floodlight is suitable for applications including:

• Commercial car parks
• Industrial and storage yards
• Building perimeters
• Loading and service areas
• Schools and leisure facilities
• Horse arenas and ménages
• Smaller sports and training areas
• Security lighting
• General exterior lighting
• Suitable for all lighting-column installations

Free Professional Lighting Design

Wydels offers a free professional lighting-design service to help determine the appropriate floodlight wattage, quantity, mounting height and positioning for your project.

Our lighting calculations can assess expected average illumination, minimum illumination, maximum illumination and overall uniformity across the proposed area.

Send us a site drawing, scaled plan or the dimensions of the area together with any proposed lighting-column or mounting positions.

Contact Wydels on 01536 264064 or email at enquiries@wydels.co.uk.

Technical Specification:

Specification	50 / 80 / 100W	100 / 120 / 150W	100 / 150 / 200W
Selectable Power	50W / 80W / 100W	100W / 120W / 150W	100W / 150W / 200W
Lumens at 4000K	8,194 / 13,110 / 16,387 lm	17,043 / 20,452 / 25,565 lm	16,030 / 24,045 / 32,060 lm
Efficacy at 4000K	163.9 lm/W	170.4 lm/W	160.3 lm/W
Colour Temperature	3000K / 4000K / 5000K	3000K / 4000K / 5000K	3000K / 4000K / 5000K
Beam Angle	110° Symmetrical	110° Symmetrical	110° Symmetrical
CRI	≥80	≥80	≥80
Input Voltage	230V	230V	230V
IP Rating	IP65	IP65	IP65
Material	Die-Cast Aluminium / Toughened Glass	Die-Cast Aluminium / Toughened Glass	Die-Cast Aluminium / Toughened Glass
Finish	Black	Black	Black
Weight	3kg	5kg	5kg
Rated Life	50,000 Hours	50,000 Hours	50,000 Hours
Operating Temperature	-40°C to +45°C	-40°C to +45°C	-40°C to +45°C
Warranty	7 Years	7 Years	7 Years
