Rutland 1200X Windcharger 12V, 24V & 48V
Land Based Windchargers
When you need power at a remote site the Furlmatic model Windchargers provide a reliable and cost effective solution. Power generated can be used for off grid homes, remote telecommunications, monitoring, and electric fences, avoiding the costly and inconvenient installation of grid power.
The Furlmatic Windchargers protect themselves by reducing the rotational speed of the turbine in extremely high winds in a design that continues to stand the test of time. For temporary installations and land installations the smaller wind turbines can be used to keep batteries topped up.
About The Rutland 1200X Windcharger
When you need a reliable source of power at an off-grid site, take a look at the Rutland 1200 Terrain turbine. Designed, developed and manufactured in the UK, our latest Rutland 1200 Terrain is available in 12V, 24V and 48V models.
What is the Rutland 1200X suitable for?
- Railways & Highways
- Environmental Monitoring Sites
- Telecommunications Sites
- Remote Homes
- Caravans
- Motorhomes
Specifications
| Cut in Windspeed | 2.5 m/s |
| Output Voltages Available (Nominal) | 12V | 24V | 48V |
| Power / Current Ratings | |
| 5m/s 11mph | 40W (2.9A) | 40W (1.45A) | 40W (0.75A) |
| 11m/s 25mph | 290W (21.3A) | 290W (10.7A) | 290W (5.35A) |
| 15m/s 33mph | 483W (35A) | 483W (17.5A) | 483W (8.75A) |
| Packed Weight and Dimensions | 11.25kg 900x390x185mm |
| Generator Type | Low friction brushless 3 phase alternator with high specification rare earth magnets |
| Yaw Rotation | Slipring and brush gear for 360º free rotation |
| Governing Devices | Electronic stalling for electrical protection and to prevent over-charging |
| Post Fixing Internal/External Diameter | 41mm / 48mm over a minimum of 600mm length to clear blade tips |
| Minimum Tower Height | 6m on land |
| Turbine Diameter | 1200mm |
| Turning Radius | 620mm |
| Turbine Net Weight | 7.8kg |
Materials
Marlec construct the Rutland wind turbines using a range of modern and traditional high quality materials which are designed to endure in a marine environment. They have innovated in the field by introducing light weight but robust high density nylon and glass reinforced materials that are UV stable alongside marine grade aluminium, stainless steel, sealed for life bearings and other carefully selected and precision worked materials in their UK factory.
Rutland 1200X Windcharger 12V, 24V & 48V
Sale price£1,250.00
